The Elements of UML 2.0 Style
Cambridge University Press, 7/14/2005
EAN 9780521616782, ISBN10: 0521616786
Paperback, 202 pages, 17.5 x 11.4 x 1.5 cm
Language: English
For all developers who create models using the Unified Modeling Language (UML) 2.x The Elements of UMLâ„¢ 2.0 Style sets the rules for style that will improve your productivity - especially in teams, where understandability and consistency are critical. Coming from renowned UML expert Scott Ambler, the book furnishes a set of rules for modelling in the UML and describes a collection of standards and guidelines for creating effective UML diagrams that will be concise and easy to understand. It provides conventions for: Class diagrams; Timing Diagrams; Use case diagrams; Composite Structure Diagrams; Sequence diagrams; Interaction Overview Diagrams; Activity diagrams; Object diagrams; State machine diagrams; Package diagrams; Communication diagrams; Deployment diagrams and Component diagrams. The Elements of UMLâ„¢ 2.0 Style sets the rules for style that will improve your productivity.
1. Introduction
2. General diagramming guidelines
3. Guidelines for common UML modeling elements
4. UML use case diagrams
5. UML class diagrams
6. UML package diagrams
7. UML sequence diagrams
8. UML communication diagrams
9. UML state machine diagrams
10. UML activity diagrams
11. UML component diagrams
12. UML deployment diagrams
13. UML object diagrams
14. UML composite structure diagrams
15. UML interaction overview diagrams
16. UML timing diagrams
17. Agile modeling
18. Summary
19. Bibliography
20. Index.
